Portable Cart Liquid Fillers - Time Gravity
(Specifications Page)


Portable Cart Liquid Filler - Time Gravity by Packaging Dynamics, Ltd. - Manufacturer of Automatic & Semi-Automatic Liquid fillers, Conveyors, Unscramblers, Accumulators, and Custom Designed Packaging machinery & nozzles for liquids.

Features

  • PLC Controlled
  • Timed Nozzle Operation
  • Stainless Steel & FDA Approved Contact Parts
  • Time-Gravity System
  • Portable
  • Quick Change Rail Adjustments
  • Product Level Float Switch Monitor
  • Pneumatic Diaphragm Pump
  • NEMA 4 Electrics
  • 15 Gallon Polyethylene Tank



Options

  • Stainless Steel Product Tank
  • Stainless Steel Product Pump
  • Bottom Fill Nozzles
  • Product Mixer
  • Larger Fill Valves
  • Power Conveyor
  • Sanitary Connections


Specifications

Description


Container Size Range: 2 oz. to 128oz.
Nozzles available: 2 to 6
Controls: Manual container stop
PLC Controlled Nozzle timers to within 1/100th sec.
Production rate: Subject to product , container review & manual operation
Construction Material: Stainless steel/aluminum
Overall dimensions: 72.5”H x 38.5”W x 27.5”D
Electrics   Requirements: 110 VAC / 1Ø / 60 Hz
Air consumption: 4 to 6 scfm
Weight:

Approximately 75 lbs.
